Commercial Storefront Door

McKinley Series

The commercial storefront doors with the variations that fit your needs. The McKinley door system can be fabricated as a narrow- or medium-stile, non-impact door and it list of optional hardware lends itself well to multiple applications be it for exterior, non-impact storefront projects or interior build outs.

The McKinley door system is available with pivots or hinges, a selection of push/pulls or panic devices or can be equipped with a residential 3-point latch lever.

Features

  • Door material - aluminum alloy 6063-T6
  • Narrow stile - horizontal and vertical members 1.75" by 4.50". Stiles 2.125". Top and bottom rail 4.5".
  • Glazed with 1/4" tempered glass or 1" IG
  • Dry glazed using extruded aluminum glazing stop and EPDM gaskets
  • Extruded aluminum pivots or stainless steel butt hinges.
  • Screw adjuster for leveling

Options & Add-Ons

  • Residential 3 point latch lever
  • Panic equipped Regent Model #5770 (Can be electrified)
  • Pivots or hinges
  • Transom to 10'
  • 10" bottom rail*

Approval Documentation

Drawing

Specifications

1/4" Glazing

1" Glazing

Glazing Options1/4" Tempered
Product ApprovalNOA, FBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
Glazing Options1" Insulated Glass
Product ApprovalPending
TAS 201Passed
TAS 202Passed
TAS 203Passed
