Commercial Glass Outswing Impact Door
K2 Summit Outswing
When you need an impact door with options, the K2 Summit Outswing is the pinnacle of commercial glass outswing impact doors. Designed to withstand high design pressures, the K2 Summit can be built to 8" x 10" pairs
It can also be equipped with a myriad of options including 4 different types of panic hardware, optional 3/4" jambs, a 10" bottom rail and more.
Features
- Up to 8' 0" x 10' 0" pairs
- 2010 energy code compliant
- Panic equipped with Adams Rite or Sargent - Can be electrified
- Panic equipped with Von Duprin and Regent to 8" - Can be electrified
- 9/16" laminated or 1 5/16" laminated-insulated glass
- ADA bumper threshold
Options & Add-Ons
- Multiple panics
- Insulated laminated glazing
- Residential 3 point latch lever
- Butt hinges or continuous gear hinges
- 10" bottom rail
- 3/4" jambs
Approval Documentation
Drawing
Installation Instructions
Specifications
9/16" Glazing
15/16" Glazing
9/16" Glazing
9/16" Glazing
15/16" Glazing
Glazing OptionsHS Uvekol
Design Loads+100/-100 psf
ReinforcedNon-Reinforced
Max Panel 72" x 108" (optional transom to 10')
Approved PanicsRegent 4770, Max Dim 6' x 8'
Product ApprovalMD, NOA, FBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
ANSI Z97Passed
Glazing OptionsHS Uvekol
Design Loads+100/-100 psf
ReinforcedNon-Reinforced
Max Panel 72" x 108" (optional transom to 10')
Approved PanicsRegent 4770, Max Dim 6' x 8'
Product ApprovalMD, NOA, FBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
ANSI Z97Passed
Glazing OptionsUvekol Annealed
Design Loads+90/-90 psf
ReinforcedNon-Reinforced
Max Panel 72" x 108" (optional transom to 10')
Approved PanicsVon Duprin, Max Dim 6' x 8'
Product ApprovalMD, NOA, FBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
ANSI Z97Passed
Glazing Options.090 Saflex Annealed
Design Loads+90/-90 psf
ReinforcedReinforced
Max Panel 96" x 120" (optional transom to 12')
Approved PanicsSargent, Max Dim 8' x 10'
Product ApprovalMD, NOA, FBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
ANSI Z97Passed
Glazing Options.090 Saflex HS
Design Loads+90/-90 psf
ReinforcedReinforced
Max Panel 96" x 120" (optional transom to 12')
Approved PanicsAdams Rite, Max Dim 8' x 10'
Product ApprovalMD, NOA, FBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
ANSI Z97Passed
