Impact Front Glazed Storefront System

FS-300 Series

The FS-300 front glazed storefront system is the best front set, impact storefront system on the market with higher design pressures, larger panel sizes and easier assembly than any competing product.

The patent pending FS-300 system is the is the culmination of design efforts involving glaziers, engineering firms, architects, and Aldora's product development team, plant personnel and sales force.

Multi-level orange building with grey outsets and stone accents, FS-300 Impact front set double panel windows with aluminum framing by Aldora, grid curtain wall windows in stone accent section of building

Features

  • 1.50" x 4.50" profile plus 3/4" front set
  • Laminated (9/16") or laminated-insulated (1 5/16")
  • Maximum single panel size of 5' x 12'
  • Design pressures of
  • +/- 90 psf non-reinforced
  • +120/-135 psf reinforced
  • 18 psi water resistance
  • Achieves 2010 energy code requirements
  • Screw spline or shear block assembly
  • Flush stop available for 9/16" glass

Options & Add-Ons

  • Can be pre-glazed
  • Thermal break
  • Free standing jambs

Approval Documentation

Drawing

Request CAD Drawing

Specifications

PVB Glazing

Uvekol Glazing

SGP Glazing

Glazing OptionsPVB 9/16" Heat Strengthened
Design Loads+65/-75 psf
ReinforcedNon-Reinforced
Max Panel 60" x 120"
Product ApprovalMD, NOA, FBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
ANSI Z97Passed
Glazing OptionsUvekol 9/16" Heat Strengthened
ReinforcedReinforced
Max Panel 60" x 144" (PVB - 48" x 120")
Product ApprovalMD, NOA, FBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
ANSI Z97Passed
Glazing OptionsSGP 9/16" Heat Strengthened
Design Loads+120/-135 psf
ReinforcedReinforced
Max Panel 60" x 144" (PVB - 48" x 120")
Product ApprovalMD, NOA, FBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
ANSI Z97Passed
