Impact Storefront System

SMI-090 Impact Series

The system that lets you select multiple varieties of glass and glazing to built projects with maximum protection. The SMI-090 impact storefront system has an adjustable glazing pocket that allows for varying glass thicknesses including 9/16" laminated and 1 5/16" laminated insulated glass as well as flood-resistant glazing.

The SMI-090 non-weep, wet seal system uses a screw spline assembly that enables pre-glazing. And to reach today's energy requirements, the SMI-090 system can also be thermally broken.

Aldora SMI-090 windows run down the corner of a commercial cement building

Available Colors

Exact colors may differ

Features

  • Aluminum alloy 6063-T6
  • Horizontal and vertical framing members 1 3/4" by 4 1/2"
  • Glazing options
  • Impact - 9/16" laminated or 1 5/16 laminated insulated
  • Non-Impact - 1/4" tempered or 1" IG
  • Flood barrier - up to 1 5/16" multi laminated
  • Screw spline assembly
  • Stainless steel assembly screws
  • High design pressures
  • Non-weep sealed system
  • Free Standing Jambs

Options & Add-Ons

  • Pre-fabricated frames
  • Pre-glazed frames
  • Stretch-forming for radius shapes
  • Segmented radius
  • Thermal break
  • Prepared to receive an approved PTAC Louver

Approval Documentation

Drawing

Installation Instructions

Request CAD Drawing

  • This field is for validation purposes and should be left unchanged.

Specifications

9/16" Glazing

9/16" Glazing

1 5/16" Glazing

1 5/16" Glazing

Glazing OptionsUvekol (.100) 9/16" Heat Strengthened
Product ApprovalMD, NOA, FBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
ANSI Z97Passed
Glazing OptionsSaflex HP (.100) 9/16" Heat Strengthened
ReinforcedNon-Reinforced
Max Panel 48" x 96"
Product ApprovalMD, NOA, FBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
ANSI Z97Passed
Glazing Options1 5/16" Uvekol (.100) Insulated Laminated
ReinforcedReinforced
Max Panel 48" x 120"
Product ApprovalMD, NOA, FBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
ANSI Z97Passed
Glazing Options1 5/16" Saflex HP (.100) Insulated Laminated
ReinforcedReinforced
Max Panel 48" x 120"
Product ApprovalMD, NOA, FBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
ANSI Z97Passed
