Non-Impact Flush Glazed Storefront System

SMI-45 Series

You'll be blown away by the versatility of the SMI-45 flush glazed storefront system. Tested both with steel reinforcement to achieve maximum wind loads and without reinforcement to minimize costs, this standard non-impact, flush-glazed storefront system is designed to meet the requirements of both interior and exterior applications.

And if you need more options, gasket variations allow for glazing 1/4" or 3/8" (interior applications) glass in the system.

Features

  • Features traditional flush glazed style
  • Framing aluminum alloy 6063-T6
  • Horizontal and vertical members 1.75" by 4.50"
  • Glazed with 1/4" or 3/8" tempered glass
  • Maximum panel size 48" x 120"
  • Dry glaze gasket system using EPDM gaskets
  • Screw spline assembly - can be unitized
  • No visible fasteners

Options & Add-Ons

  • Can be pre-fabricated
  • Can be segmented

Approval Documentation

Drawing

Request CAD Drawing

Specifications

1/4" Glazing

3/8" Glazing

Glazing Options1/4" Tempered
Design Loads+120/-120 psf
ReinforcedNon-Reinforced
Max Panel 30" x 144"
Product ApprovalFBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
Glazing Options3/8" Tempered - Primarily interior applications
ReinforcedReinforced
Max Panel 30" x 144"
Product ApprovalFBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
