Non-Impact Pre-Glazed Storefront System

SMI-090 Non-Impact Series

The non-impact aluminum storefront system that gives you glazing options. The non-impact version of the SMI-090 storefront system is both non-weep and wet seal system.

With its screw spline assembly and installation hole locations behind the glazing pocket, the SMI-090 is one of the only non-impact systems that can be pre-glazed, and the glazing pocket is adjustable, allowing for 1/4" tempered or 1" insulated glass. The system can also be thermally broken in order to improve energy performance when used with insulated glass.

Features

  • Aluminum alloy 6063-T6
  • Horizontal and vertical framing members 1 3/4" by 4 1/2"
  • Glazing options
  • Impact - 9/16" laminated or 1 5/16" laminated insulated
  • Non-Impact - 1/4" tempered or 1" IG
  • Bullet resistant or flood barrier - up to 1 5/16"
  • multi laminated
  • Screw spline assembly
  • Stainless steel assembly screws
  • High design pressures
  • Non-weep sealed system
  • Free Standing Jambs

Options & Add-Ons

  • Pre-fabricated frames
  • Pre-glazed frames
  • Stretch-forming for radius shapes
  • Segmented radius
  • Thermal break

Approval Documentation

Drawing

Request CAD Drawing

Specifications

1/4" Glazing

1" Glazing

Glazing Options1/4" Tempered
ReinforcedNon-Reinforced
Max Panel 36" x 120"
Product ApprovalFBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
Glazing Options1" Insulated
ReinforcedReinforced
Max Panel 36" x 144"
Product ApprovalFBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
