Non-Impact Flush Glazed Storefront System (Insulated Glass)

SMI-245 Series

When you need easy install with a variety of variables, the SMI-245 system offers you options. The non-impact aluminum storefront system is a 2" flush glazed system designed to accommodate 1" insulated glass. And by utilizing different gaskets, it can be configured to house 1/2" tempered glass for interior projects.

Need a simplified install? With its screw spline assembly, the SMI-245 can be pre-fabricated for easy installation.

Available Colors

Exact colors may differ

Features

  • Framing - aluminum alloy 6063-T6
  • Horizontal and vertical members 2.00" by 4.50"
  • Glazed with 1" insulated glass or 1/2 tempered glass
  • Maximum panel size 48" x 120"
  • Dry glaze gasket system using EPDM gaskets
  • Screw spline assembly - can be unitized
  • No exposed fasteners

Options & Add-Ons

  • Can be pre-fabricated
  • Can be segmented

Approval Documentation

Drawing

Installation Instructions

Request CAD Drawing

  • This field is for validation purposes and should be left unchanged.

Specifications

1/2" Glazing

1" Glazing

Glazing Options1/2" Tempered - Primarily interior applications
ReinforcedReinforced
Max Panel 36" x 144"
Product ApprovalFBC
TAS 201Passed
TAS 202Passed
TAS 203Passed
ANSI Z97Passed
Glazing Options1" Insulated Glass
Design Loads+120/-120 psf
ReinforcedNon-Reinforced
Max Panel 48" x 120"
Product ApprovalFBC
TAS 201Passed
TAS 202Passed
ANSI Z97Passed
